Linear Actuator HLS12-RS485-50380

Item No.: 1-03311

4 - 8,4 V | 50 mm | 380 : 1 | max. 217,71 N | max. 4,1 mm/s

Contents:

1x HiTEC Linear actuator HLS12-RS485-50380
Mounting hardware

Description Technical data Mandatory Accessories Downloads Alternate articles

Description

The HiTEC linear actuator HLS12-RS485-50380 delivers powerful, controlled linear motion in a compact footprint and communicates clearly over RS-485. A brushed motor with a metal core drives a durable metal gear train, transferring power precisely across the 50 mm (1.97 in) stroke. The 380:1 gear ratio provides finely metered feeds at 4.1 mm/s (0.16 in/s) at 7.4 V, while up to 217.71 N (48.96 lbf) of thrust enables confident positioning under load. Programmability adds application flexibility, and the wide 4.0–8.4 V operating range simplifies power planning. The result is repeatable accuracy with clean response in a space-saving actuator built for precise travel and robust RS-485 integration.

For further technical advice, please contact our Technical Support team📧.

Technical data

Length (mm)

102,00

Width (mm)

15,00

Height (mm)

18,00

Weight (g)

40,00

Communication

RS485

output length (mm)
