Servo MD981TW
Item No.: 1-01640
4,8-7,4 V | max. 431,49 N/cm | max. 0,17 Sek/60° | IP54
Contents:
- 1x HiTEC Servo MD981TW
- Servo arm set (HD-IM25, HD-LS25, HD-OS25, HD-X25, HD-IL25, HD-LL25, HD-IG25, HD-LG25)
- Mounting hardware
Description
The HiTEC servo delivers speed and precision in a compact form. A non-contact magnetic encoder ensures wear-free position feedback and clean centering. Through proven PWM/TTL, the actuator integrates into existing controllers, and its programmability enables precise parameterization. At 7.4 V, the coreless motor achieves 0.17 s per 60° and develops 431 N·cm of torque. The 3.5–8.4 V range supports flexible power concepts. A titanium gear train transfers power efficiently. With IP54 protection, the servo resists dust and splashing water. The MD981TW concentrates speed and control for precise motion in tight spaces.
For further technical advice, please contact our Technical Support team📧.
For further technical advice, please contact our Technical Support team📧.
Technical data
Width (mm)
22,40
Motor Type
Coreless
Encoder
Magnetic Encoder
IP Protection Class
IP54
Communication
PWM / TTL
Servo Type
Digital
Voltage max. (V)
7,40
Torque max. (kg/cm)
44,00
Setting Speed max. (sec/60 degrees)
0,17
Hitec Servo Series
MD-Series
Weight (gramm)
94,20
Horn Gear Spline
H25T (Ø6,0mm)
Length (mm)
43,80
Height (mm)
40,00
Voltage min. (V)
4,80
Torque min. (kg/cm)
26,00
Setting Speed min. (sec/60 degrees)
0,28
Angle Standard (degrees)
± 60°
Rotation Angle programmable (degrees)
320°
Multi Turn
not possible
Contniuos Rotation
No
Current Draw at idle (mA)
30
Current Draw max. (mA)
6200
Torque min. (N/cm)
254,97
Torque max. (N/cm)
431,49
Housing
Aluminum Alloy
Connector
Hitec 3 Pin (Uni)
Gearing (characteristic)
Titanium Alloy
