Servo MD245MW-RS485
Item No.: 1-01677
4,8-7,4 V | max. 62,76 N/cm | max. 0,11 Sek/60° | IP4X
Contents:
- 1x HiTEC Servo MD245MW-RS485
- Servo arm (M-O25)
- Mounting hardware
Beschreibung
The HiTEC servo delivers repeatable motion thanks to its non-contact magnetic encoder. Its coreless motor responds instantly, reaching 0.11 s per 60° at 7.4 V with 62 N·cm of torque to keep dynamic cycles under tight control. Via the RS-485 interface, the actuator communicates reliably in networked systems, while programmability lets you fine-tune parameters to your motion profile. The 4–8.4 V supply range simplifies power design. A robust metal gear train transfers power efficiently and ensures smooth running.
For further technical advice, please contact our Technical Support team📧.
For further technical advice, please contact our Technical Support team📧.
Technical data
Width (mm)
16,80
Motor Type
Coreless
Encoder
Magnetic Encoder
IP Protection Class
IP4X
Communication
RS-485
Servo Type
Digital
Voltage max. (V)
7,40
Torque max. (kg/cm)
6,40
Setting Speed max. (sec/60 degrees)
0,11
Hitec Servo Series
MD-Series
Weight (gramm)
35,20
Horn Gear Spline
H25T (Ø6,0mm)
Length (mm)
32,40
Height (mm)
32,80
Voltage min. (V)
4,80
Torque min. (kg/cm)
4,20
Setting Speed min. (sec/60 degrees)
0,17
Angle Standard (degrees)
± 60°
Rotation Angle programmable (degrees)
320°
Multi Turn
not possible
Contniuos Rotation
No
Current Draw at idle (mA)
30
Current Draw max. (mA)
1600
Torque min. (N/cm)
41,19
Torque max. (N/cm)
62,76
Housing
Engineering Plastic
Connector
Hitec 4 Pin (Uni)
Gearing (characteristic)
Metal
