Servo HSB-9381TH with PAD
Item No.: 1-00074
20mm HSB-9381TH, Brushless, High Voltage, Ultra Torque, Titanium Gear Actuator (7.4V)
Contents:
- 1x HiTEC Servo HSB-9381TH
- Servo arm set (HD-IM25, HD-LS25, HD-OS25, HD-X25)
- Mounting hardware
Description
The HiTEC servo motor HSB-9381TH pairs a contactless magnetic encoder with an efficient brushless DC motor for dynamic, repeatable actuator motion. A proven PWM interface enables quick command input, while the programmable feature set adapts behavior to specific motion profiles. The wide 4–8.4 V supply range gives designers latitude in power architecture. At 7.4 V the digital servo reaches 0.14 s for 60° and delivers 333 N cm of torque, ideal for forceful moves with precise stops. The titanium gear train transfers power with lasting precision and keeps backlash low, even under high load. Rated IP54, it maintains reliable operation in environments with harmful dust and splashing water.
For further technical advice, please contact our Technical Support team📧.
For further technical advice, please contact our Technical Support team📧.
Technical data
Width (mm)
20,00
Motor Type
BLDC
Encoder
Potentiometer
IP Protection Class
IP54
Communication
PWM
Servo Type
Digital
Voltage max. (V)
7,40
Torque max. (kg/cm)
34,00
Setting Speed max. (sec/60 degrees)
0,14
Hitec Servo Series
HSB-Series
Weight (gramm)
79,00
Horn Gear Spline
H25T (Ø6,0mm)
Length (mm)
40,00
Height (mm)
38,00
Voltage min. (V)
6,00
Torque min. (kg/cm)
34,00
Setting Speed min. (sec/60 degrees)
0,17
Angle Standard (degrees)
± 60°
Rotation Angle programmable (degrees)
160°
Multi Turn
not possible
Contniuos Rotation
No
Current Draw at idle (mA)
27
Current Draw max. (mA)
2100
Torque min. (N/cm)
333,50
Torque max. (N/cm)
333,50
Housing
Aluminum Alloy
Connector
Hitec 3 Pin (Uni)
Gearing (characteristic)
Titanium Alloy
